SPECIFICATIONS



Features

1.Off grid solar inverter

2.No battery function available

3.Under Battery Mode can adjust AC voltage 100VAC,110VAC and 120VAC.

4.Utility power, battery and PV power complement each other

5.Pure sine wave solar inverter

6.Unique glass top cover design with 6.25inch LCD display and touchable buttons

7.Built-in 140A MPPT (Max PV5600W) solar charger

8.High PV input range from 55~350Vdc

9.Smart battery charger design for optimized battery performance

10.Configurable AC/Battery input priority via LCD setting

11.Auto restart while PV is recovering

12.Over-load , over temperature and output short circuit protection

13.Cold restart function Built-in lithium battery automatic activation

14.Communication with RS232/RS485

15.WiFi monitoring function (optional )

16.Anti-dust kit for harsh environment(optional)

17.Restore default Settings with one click
